01D140 Diaphragm pump SAMES KREMLIN

01D140 Diaphragm pump

Paint pumps and paint application products

Vote

“ ULTIMATE HIGH PERFORMANCE AND COMPACT DESIGN DIAPHRAGM PUMP! - Perfect for frequent color changes - Reliable and durable - Low cost of ownership ”

Ask for a quote

Presentation

01D140 is the new pneumatic, double diaphragm pump from SAMES KREMLIN designed for fluid transfer and small circulating systems with multiple guns.

This pump benefits from a compact design making it very easy to integrate into paint systems. Its advanced construction guarantees fast flushing which makes the pump perfectly adapted for fast color-changing systems.

For waterborne abrasive product applications such as porcelain and ceramic, the 01D140E is designed with specific EPDM diaphragms. The 01D140E has the same benefits and components as the 01D140 except for the diaphragm material.

Durable pump, all stainless steel body, ceramic pneumatic valve, and long-lasting PTFE diaphragms

Technical features

Pressure ratio : 1:1 Maximum air pressure : 8 bar / 116 psi Maximum temperature : 65°C / 149°F Sound level : 68 dBa Maximum viscosity : 15000 cps Fluid outlet : 3/4 Fluid inlet : 3/4 Height : 174 mm / 6.85 in Width : 130 mm / 5.1 psi Weight : 6.2 kg / 13.2 lbs

Download the complete technical features
