CXS Chemical dry pumps : CXS250 ATEX CAT 2&3 T3 Light duty

Vacuum pump

Vote

Ask for a quote

Presentation

Overview Edwards pioneered the industrial dry vacuum pump in 1986 and now with more than 150,000 systems sold worldwide this Edwards expertise has been used to develop a dry pump capable of withstanding the harshest of process applications.

The CXS incorporates innovative screw design features with simplicity and reliability in mind, a ‘Plug and Pump’ philosophy has been adopted. As a result, the CXS has industry leading reliability, safety and low cost of ownership.

Continuous vacuum from atmosphere to 10-3 mbar
Integral temperature control
Pumps corrosive vapours without deterioration
Excellent liquid and solids handling
Deeper vacuum than traditional technologies - not limited by seal fluid or cooling water temperature

Technical features

Maximum pumping speed : 250 m3h-1 / 148 ft3min-1 Capacity at 10 mbar (7.5 Torr) : 230 m3h-1 / 135 ft3min-1 Ultimate vacuum : <0.015 mbar / <0.011 Torr Maximum back pressure - standard : 1,200 mbar / 2.7 psig Power consumption at 10 mbar (7.5 Torr) : 3.8 kW / 5.1 hp Standard motor (200 - 230V ±10%, 3 ph, 50/60 Hz) : 7.5 kW Cooling water flow rate, (adjustable) : 4 - 10 l min-1 / 1.1 - 2.6 gal min-1

Download the complete technical features
