Electronic Pressure Switch EPN-S 8320 Trafag AG sensors & controls

Electronic Pressure Switch EPN-S 8320

Pressure transmitter

Vote

Ask for a quote Receive Documentation Contact the supplier

Trafag pressure transmitters are used for electronically measuring and evaluating pressure. Over the decades they have proven themselves in a multitude of demanding applications in harsh environments. They are available in many different designs to suit pressure and electrical connections, measuring procedures, electrical output signals and certifications (CE, EX, rail and ship). Superior technology and precise manufacturing ensure that the transmitters work perfectly. This is especially important in applications where high requirements are placed on long-term stability, vibration resistance, electromagnetic compatibility, shock resistance or temperature insensitivity.
The Electronic Pressure Switch EPN-S is based on the well-proven EPN transmitter family. It stands for reliable accuracy over a wide temperature range and excellent long-term stability even in harshest environments in the shipbuilding and railway industry. The switchpoint is factory set or can be programmed on site using Trafag’s Sensor Communicator SC.
Applications
Shipbuilding
Engine manufacturing
Railways
Machine tools
Hydraulics
Main features
Rugged design for harsh environments
Wide temperature range
Excellent long-term stability
Very compact design
Switchpoint factory set or programmable on site with Trafag Sensor Communicator SC

Applications: Shipbuilding<BR>Engine manufacturing Main features: Rugged design for harsh environments Measuring principle: Thin film on steel Measuring range: 0 ... 2.5 to 0 ... 600 bar<BR>0 ... 30 Output signal: Transistor (open source) Accuracy @ 25°C typ.: ± 0.5 % FS typ. (Switchpoint) Media temperature: -40°C ... +125°C Ambient temperature: Standard: -25°C ... +85°C Approval: GL Output / supply voltage: Transistor (open source): 24 (9 ... 32)
Download the complete technical features
