High Definition Uncooled LWIR thermal camera VayuHD (1920x1200 pixels 12µm)

Vote

“ - Image resolution >2Mpixels (microbolometer VOx 1920x1200pixels 12µm pitch) - NETD 50mK @ f/1.0 - Frame rate: 60Hz - Small size and weight (SWaP) - IP54 housing ”

Ask for a quote

Presentation

The VayuHD-I thermal camera, designed around a VOx microbolometer sensor with 1920x1200 resolution and 12µm pitch, is one of the highest image definition products in its class.
Offering a response in the 8-14µm spectral band (uncooled LWIR), it provides users with a wide range of thermal imaging applications for markets such as machine vision, security/surveillance, robotics, etc.

The VayuHD-I camera features the following key characteristics:
- NETD 50mK at f/1
- 60Hz image frequency
- Compact size and low weight (example: 85x85x95mm and 510g with 25mm optics or 695g with 50mm optics)

Several digital outputs are availableSDI (1080p), IP Video (H.264/265) or USB3.0 UVC (16-bit RAW).
Three f/1.2 lenses are available: 25mm, 50mm, 87mm.

Dual-use export classification (6A003b.4)

Its export classification is dual use (6A003b.4)

Technical features

VOx microbolometer sensor 1920x1200 resolution at 12µm pitch Spectral response band 8-14µm (LWIR) NETD : nominal 50mK f/1.0 Image frequency : 60Hz Available digital outputs : USB3.0 UVC, SDI, IP Video (H.264/265) Power consumption : 12W nominal (11-14VDC) Available lenses : 25, 50mm, 87mm f/1.2 Camera control : Ethernet, RS-422/RS-232 Operating temperature : -15 to +65°C Dual use export license (6A003b.4)

Download the complete technical features
