Advanced Swept Sine is a measuring instrument that allows to determine Transfer Function or Frequency Response Function that are commonly used in various industries for Servo control, Structure, Acoustics, Electronics or Accelerometers calibration.
Frequency Response determination is commonly used in various industries for:
• Servo Control: steppers, machine tools, guiding systems
• Structure: accurate FRF for modal acquisition with excellent mode separation and non linear structure
• Acoustics: absorption materials, audio systems
• Electronics: filters, amplifiers
• Accelerometers calibration
The challenges for determining the Frequency Response are the frequency resolution, an excitation level control (control of the energy transferred to the system, enough for getting a good signal/noise ratio, but not too much for avoiding non-linear phenomena) and speed of the measurement.
A2S gives the most adapted answer to these requests, and compared to the standard functions included in a FFT analyzer, A2S dramatically overpasses the capabilities of a random or swept sine excitation coupled with a peak hold FFT.
High precision and very low noise frequency response function determinationHigh frequency resolution: continuous sweep up to 80,000 pointsPure tone excitationFrequency range from 0.01 Hz to 40 kHz, in 1 to 8 independent spansAutomatic control of the generator output level to get constant level either at input or output system under testUser defined level/frequency templateBoosted mode to speed up the measurementDisplay Frequency Response, Coherence, SpectrumBode and Nyquist plotsExport to Excel, Matlab and others
