ÖLFLEX® HEAT 125 C MC - halogen free single core with GL certificate, special fire performance, IEC 60332-3, suitable for +125°C
-
CPR: Article number choice under www.lappkabel.com/cpr
-
VDE-tested and -marked
-
Improved characteristics in the event of a fire
Benefits
-
For safety in areas with high density of people
-
Reduction of flame propagation, density and toxicity of smoke gases in event of fire
-
Minimises damage to buildings and equipment caused by the formation of toxic acid fumes in fires
-
Certified for maritime applications
Application range
-
For the wiring and connection of lighting, heating appliances, control cabinets, and distributors in mechanical and plant engineering
-
For installation in tubes, on, in and under plaster as well as in closed installation ducts
-
Coil winding, electromagnets, pumps, electrical systems
-
Heat treatment plants, pressure die casting, heating and cooling technology
-
Suitable for assembling cable harnesses and wiring during switch cabinet installation
Product features
-
Fire behaviour:
- Flame-retardant (IEC 60332-1-2)
- Halogen-free (IEC 60754-1)
- No corrosive gases (IEC 60754-2)
- Low smoke density (IEC 61034-2)
- Low toxicity (EN 50305)
-
Extended fire behaviour:
H05Z-K (0,5mm² up to 1,0mm²):
see data sheet
H07Z-K (≥ 1,5mm²):
no fire propagation according to IEC 60332-3-24 respectively IEC 60332-3-25
-
Oil-resistant according to DIN EN 50290-2-22 (TM54)
-
Abrasion and notch-resistant
-
UV-resistant according to ISO 4892-2, method A, and ozone resistant acc. to EN 50396 resp. VDE 0473-396, method B
Norm references / Approvals
-
Type H05Z-K and H07Z-K according to EN 50525-3-41 with advanced features
-
Germanischer Lloyd (GL)
certificate no. 11118-14HH
Product Make-up
-
Fine-wire, tinned-copper conductor
-
Electron beam cross-linked polyolefin copolymer insulation
