5-axis horizontal Profiler for titanium aircraft parts - Forest-Liné POWERMILL Ti FIVES MACHINING

5-axis horizontal Profiler for titanium aircraft parts - Forest-Liné POWERMILL Ti

Profiling machine

Vote

“ High chip removal rate Ram with constant overhang Five-axis high torque spindle, in-house design and manufacturing High pressure and high flow rate coolant processing Safe process: GFACS, spindle monitoring ”

Ask for a quote

Presentation

5-axis horizontal Profiler designed for roughing and finishing hard materials and titanium. Primarily used to create complex structural aircraft parts such as landing gears and sliding ways.

Axis travels: X: from 4 to 6.5 m, Y: 2.5 / 3.5 m; Z: 0.8 / 1 m
Pallet size from 4 to 6 m long; 2 / 2.5 m width
Spindle: up to 60 kW, 2,500 Nm (S1)
Architecture: moving pallet, fixed column
Flexible configuration
Stand-alone or FMS configuration
Optional automatic spindle change (AAC)

Technical features

Titanium, Inconel and other hard materials High chip removal rate complex structural aircraft parts

Download the complete technical features

Usage scope

Aerospace Aerospace Aerospace
