ABES Bollard 001-1

Street terminal

Vote

Ask for a quote

Presentation

ABES Bollard 002 is a bollard made from cast aluminium with a triangular base and a sphere set on top. The bollard tapers towards its center. Mounting Removable with 3p-Technology, comprising a ground shell, a junction piece with integrated breaking point, two clamping cones and a hex head bolt. Alternative: concrete embedment. Finish – Powder coating in standard RAL colours or DB 703. Note The surface is not as smooth as that of a stainless steel tube. The basic package for ABES Bollard 002 with 3p-Technology contains: – The bollard, cast aluminium, powder coated in RAL, DB 703 Glimmer grey – Measurements (H above the ground x Ø in mm): 820 x 140 – Ground shell 300 mm (000.001), cast iron, galvanised – Junction piece (000.008), cast iron, galvanised – clamping bolt set, hex head (N1+N2+hex-screw), stainless steel 1.4301 (000.004)

Technical features

Type: for public spaces, for schools, for public buildings, kindergarten, for parking lots Material: cast aluminum Features: fixed mounted, removable with 3p-Technology

Download the complete technical features
