Flat Cable Cutter 75 - FCC 75

Plastic sawing

Vote

Ask for a quote

Presentation

Device details: ■ Save up to ⅔ measuring uncertainty with well prepared samples ■ Very robust device for quick and efficient cutting of flat cables ■ Exact adjustment of the sample thickness (depending on material) ■ Thin, evenly and parallel cut samples with a smooth surface (especially the very small and many cores require a very thin cut to avoid shadows) ■ Precise and repeatable measuring results due to reproducible samples Area of application: ■ Sample preparation according to IEC 60811 ■ Cutting device for flat cable samples up to a width of max. 75 mm (2.95“) and a height of max. 8mm (0.31“) ■ Optimal cable preparation device for measurements with offline cable measurement devices ■ Use of the FCC75 is essential for your Quality Management ■ Compact and light device to easily use in laboratories and production halls

Technical features

Size (width x length x height): 225 x 235 x 450 mm Weight: 7.7 kg (16.97 lbs) Knife: Stainless steel blade width - Cable sample: max. 75 mm (2.95 Inch) height - Cable sample: 1 - max. 8 mm (0.04 - 0.31 Inch) Length - Cable sample: min. 30 mm (1.18 Inch)

Download the complete technical features

Opinion on the product
