Impulse Welding Machine | MITEC - T-500 DOREY

Impulse Welding Machine | MITEC - T-500

Heating element welding machine

Vote

Ask for a quote Receive Documentation Contact the supplier

The MITEC - T500 impulse welding machine is used for welding signs, billboards, awnings, etc.

The 500 still includes an automatic hem from 20 to 145 mm as well as automatic overlaps, reinforcements and an integrated guide for zippers, flutes or keders for two different sizes.

With the most advanced welding functions, the operator can customize an almost unlimited number of individual and group combinations to achieve perfect welding results every time.

Operation is simple and convenient with the largest touch screen on the market, which offers real-time feedback and color-coded LEDs to visually indicate what the machine is doing.

Available in lengths from 4 to 8.4 m and bar thicknesses from 6 to 24 mm, Sigma 500 impulse welding machines offer even more built-in features for the most detailed and complex welds.


GENERAL CHARACTERISTICS (STANDARD):
  • Available sealing lengths: 4 - 6 - 8.4 or 12.4 meters (16.5 - 20 - 28 or 41 feet).
  • Available seal widths: 6, 8, 10, 12, 19, 24 millimeters (1/4", 1/3", 3/8", 1/2", 3/4" or 1").
  • Side opening (access to the folded area).
  • 10" color touch screen.
  • LED lighting of the working area.

Programming and control of the following parameters:

  • Control of the heating and cooling time of the sealing bar.
  • Control of the temperature of the sealing bar by means of probes (ºC/ºF).
  • Edition of welding programs, display of temperature graphs and visualization of parameters.
  • Preheating function to obtain a constant temperature and thus improve the quality of consecutive welds.
  • Creation of work groups (sequences of work programs to be executed automatically).
  • Electric backgauge (servo-controlled) to adjust the position of the fabric and accessories.
  • Automatic front stop to adjust the position of the fabric (assemblies) (manual adjustment).
  • Automatic folding system with electric pocket size adjustment (with frequency variator and rotary encoder) (pocket sizes from 25 to 90 mm).



TOOLS INCLUDED:
  • Magnets (2 units per meter of machine).
  • Cylinders on the sealing bar with double guide for better stability.
  • Quick change system of the sealing bar.
  • Possibility to work with different welding widths (with the same transformers).
  • Safety barriers connected to the safety automaton (approved safety elements).
  • Pneumatic safety valve.
  • Operational activation by foot switch.
  • Air pressure 6 bar.
  • 400 / 230 THREE-PHASE.

*Dimensions in feet and inches are approximations of metric dimensions.
**For machines over 6 meters, a central support assembly (feet) is incorporated.
***Electrical and pneumatic connections required for machine operation (not included).

All MITEC-T machines are manufactured in accordance with EC safety regulations.




OPTIONS:
  • Tape roll holder (acrylic fabric welding)
  • Customized guides
  • Guides with zip opening
  • Guides with opening for double groove zipper
  • Pocket width up to 150mm
  • Horizontal sealing bar from 19mm (allows "flat hem" operations)
  • Servo driven gripper and front stop set (recommended for tunnels)
  • Bar code reader
  • Pneumatically operated sealing bar lowering system
  • Electronic pressure control system
  • Additional sealing bars
  • Wider side with safety mat (side work)
  • Central supports with step for the operator (for lengths over 6 meters)
  • Wireless remote control screen (tablet style)
  • Electrical connection (length to be defined)
  • Remote connection (LAN / WIFI) for after sales service.

*Configurations that include electronic movements also allow adjustments via "offsets".
**The electronic pressure control system allows to adjust the pressure at each moment of the work performed and to visualize the pressure graphs according to the time (ideal for complicated fabrics).



ON REQUEST:
  • Customizable spouts
  • Vertical and/or horizontal sealing bar of 30 or 40mm.
  • Liquid cooling system for sealing bars
  • Double hem
  • Rollers
  • Data collection
  • Special realizations (own engineering service)

DOUBLE AND INTEGRATED GUIDES FOR SPLINE/ KEDER/ ZIPPER INTEGRATED TUNNEL GUIDES FOR BATTEN POCKETS PRESSURE CONTROL FOR PERFECT WELDING
Download the complete technical features
