LRW-112 / LRW-112PP router

The LRW-112 / LRW-112PP router offers an easy way to extend the distance between LONWORKS® 78 kbit/s TP/FT network segments using a high-speed 1.25 Mbit/s backbone fibre optic network link. LRW-112 / LRW-112PP is based on Echelon’s RTR-10 standard router core module, this allowing standard configuration and installation with tools as LonBuilder® and LonMaker™. The LRW-112 is equipped with either one (PP-version) or two pairs of fibre optic receivers and transmitters. This allows the user to build either point to point-, bus- or ring topology fibre links. The LRW-112/112PP has a built-in redundancy scheme that provides for fault tolerances in the fibre ring.

LONWORKS®, 78 kbit/s TP/FT-10
Fibre optic 1.25 Mbit/s
Router function (based on Echelon’s RTR-10 router module)
Distance up to 20 km on fibre
Point to point (LRW-112 PP)
Multidrop or redundant ring
Optical signal regenerated
Multi- / Single mode fibre
Alarm output indicating fibre failure
