Machining Centre C 62 Maschinenfabrik Berthold HERMLE AG

Machining Centre C 62

Vote

Ask for a quote

Presentation

The C 62 is a highly dynamic machining centre designed for 5-axis/5-side machining.
Numerous features ensure high-precision and cost-effective working on workpieces up to 2500 kg in weight. Various optional extras simply add to the capabilities for innovative advanced machining. As with all HERMLE machining centres, the C 62 offers various workpiece loading options to guarantee optimum operation. Depending on the respective requirements, various additional tool magazines are available. The concept and modular design of the C 62 means individual needs can be met in many different ways. The optimised footprint is another bonus besides the highest standards of quality, precision and accuracy which are synonymous with HERMLE. The C 62: a high-performance all-rounder. In short: a new giant.
Milling and turning in one clamping. Fully integrated rotary technology.

Technical features

Traverse X-axis: 1200 mm Traverse Y-axis: 1300 mm Traverse Z-axis: 900 mm Rapid linear traverses X-Y-Z: 50 m/min Linear acceleration X-Y-Z: 6 m/s² Linear feed force X-Y-Z: 16000 N Max. vertical table clearance: 1100 mm Max. workpiece diameter: Ø 1200 mm Max. workpiece height: 900 mm Collision circle (A axis) in 0° position: Ø 1400 mm

Download the complete technical features
