MIPI LWIR 320x240 infrared module E2Eye-320M

Thermal closed circuit TV camera

“ - 8 or 14 bit digital interface in MIPI CSI-2 (2 channels) compatible with NVidia & Raspberry PI - High-performance image: 14-bit, NETD 50mk, 60Hz - Compact size, low weight, and low power consumption ”

Ask for a quote

Presentation

The E2Eye-320M LWIR (8-14 µm) infrared module is specially designed to interface with NVIDIA or Raspberry PI GPUs.

It offers 8- or 14-bit digital output depending on the selected mode, in accordance with the MIPI-CSI2 standard compatible with NVIDIA's Jetson Nano and Jetson Xavier NX, Orin NX, or AGX versions and Raspberry Pi 4 or 5

Shutterless, it offers a resolution of 320 x 240 pixels at 12 µm pitch (Lynred ATI320 microbolometer detector) and a NETD of 50 mK.

It is designed for thermal camera developers with embedded solutions.

Its small size (30 x 30 x 10 mm) and low power consumption (<0.5 W) make it a particularly attractive product for security and industrial process control applications.

Three models are available depending on the S-mount lens selected:
- 3.15 mm f/1.2 70° horizontal field of view
- 5.3 mm f/1.3 42° horizontal field of view
- 7.8 mm f/1.0 28° horizontal field of view

Technical features

Sensor: LWIR microbolometer 320 x 240 pixels, 12 µm pitch NETD: 50 mK – shutterless Fixed focal length optics: 5.3 mm; f/1.3 (HFOV 40.8°); 3.15 mm f/1.2 (HFOV 70°) Digital interface: 8 or 14-bit in MIPI CSI-2 (2 channels) Control interface: I2C (2-wire serial communication) Frame rate: 60Hz Dimensions: 30x30x10mm Weight: 125g

Download the complete technical features

Usage scope

Security - Surveillance Robotics (Drones) Fire Detection Process Control
