Multi-Vices MS 125 - EH 1700

Scope of application:

• Can be applied horizontally and vertically - therefore suitable for vertical and horizontal CNC milling machines
• Conventional clamping, gripper clamping or pull-down clamping are all possible
• MS 125-S - ideal for use on five-axis machining centres
• Clamping of unmachined parts, saw-cut or flame-cut material by penetration of hardened, replaceable gripper elements into the workpiece
• With the support jaws, unmachined parts in highly varied materials, or with complex geometries, can be clamped securely and economically

Product features:

• High versatility - the modular clamping system combines practically all the possibilities of our tried-and-tested models
• High-pressure spindle with power intensification - clamping force does not slacken
• Enlarged clamping span for secure clamping of unmachined parts
• Lost clamping margin 8 mm with pull-down clamping, 3 mm with gripp clamping
• Clamping with torque wrench (max. 30 Nm) - this makes it possible to work above the table with an unfavourable clamping arrangement on the tool

Scope of supply:

• 1 high-pressure vice without jaws
• 1 set of clamping claws
• 3 socket screw wrenches
• 1 hexagonal insert for torque wrench 3/8"

Please order the clamping jaws separately.
