PCI Express counter board, 4 FPGA with numerous functions

Vote

“ The PC boards by Addi-Data have been developed for a use in industrial environments. Thus, they are fail-safe and equipped with numerous protective circuits. Addi-Data offers boards for many signal types. The functionality or product properties can be adapted to specific requirements. Product overview PCI Express boards: Digital I/O, 24 V or TTL Relay boards Analog I/O, multifunction boards 1- to 8-port serial interfaces Counter boards: incremental counter, SSI synchronous serial interface, counter/timer, pulse acquisition, frequency, pulse width, period duration or velocity measurement, pulse width modulation (PWM), BiSS-Master, digital inputs and outputs, etc ”

Ask for a quote

Presentation

The board APCIe-1711 from Addi-Data is a fast multifunction counter board for the PCI Express bus. With this board the user can realise many different applications on the same hardware base. It is equipped with four programmable FPGA modules. The functions are individually configured for each channel through the supplied software.

Following functions are available:

Incremental counter

SSI

Counter/timer

Pulse acquisition

Frequency measurement

Pulse width modulation (PWM)

Period duration measurement

Velocity measurement

BiSS-Master

Digital inputs and outputs

Parallel Interface (parallelly acquisition of 28 digital inputs 24 V or 16 RS422/TTL inputs and 12 digital inputs 24 V

Customised functions

Wide range of drivers:

Signed 64-bit drivers for Windows 7/Vista/XP

32-bit drivers for Windows 7/Vista/XP/2000 (real-time)

Drivers and samples for numerous compilers and software packages
