Pump mechanical drive : AP18HP - AP19HP

Centrifugal pumps

Vote

Ask for a quote

Presentation

The AP18/19HP range was designed and ma,nufactured for low flowrate and high pressure applications. It’s integrated priming device coupled with double stage impellers make this pump ideal for various industrial applications :

• Circulation in ion exchange resins / activated carbon
• Viscuous fluid pumping up to 45 cst
• Effluent raising up to 30 meter high.

Highlights

• Economical polypropylen and 316L stainless pump
• Closed centrifugal double impeller with diffuser : great efficiency, enables high viscosity fluids
• Carbure / carbure seal : great wear resistant
• Volume integrated security strainer : improved pump security
• Self repriming: up to 2m aspiration
• Gaskets : NBR (other materials available on request)
• Motors : single or three-phase
• Connection : standard union nut
• Options : grooved nozzle and flanges available on request

Technical features

Seals : Carbure / carbure (others on request) Power supply : 230V or 400V threephase Frequency : 50Hz or 60Hz Rotation speed : 3 000 rpm Flowrate : AP18HP : 7,5 m3/h, AP19HP : 10 m3/h Total Head : AP18HP : 24 mWC, AP19HP : 30 mWC Max temperature : 75°C (PP) Selfrepriming : Up to 2m

Download the complete technical features
