The MZCG magnetic cylinder sensor detects the piston position in pneumatic grippers and pneumatic miniature cylinders. Thanks to its very small design, the MZCG is particularly well-suited for the C-slots of very small pneumatic actuators such as are used in handling and assembly, robotics or the electronics industry.
The sensor is simply inserted in the C-slot and can be quickly and safely fastened to the cylinder. The MZCG fits in a wide range of C-slots of various manufacturers due to its universal housing design. This reduces storage costs, enables flexible machine design and easier service.
At a glance
-
Extremely short housing (12.2 mm) for applications in pneumatic grippers and miniature cylinders
-
Fits in all commonly-used C-slots, e.g. from Schunk, Zimmer, Festo or SMC
-
Short, precise switching point, ideal for applications with small stroke
-
Cable suitable for drag chain
-
IP68 enclosure rating
-
Yellow LED as optical adjustment indicator and output state display
-
Green LED acts as a status indicator
-
IO-Link and automation functions
Fields of applications
-
Open-close position detection in pneumatic grippers
-
End position detection in pneumatic miniature cylinders
-
Industries: Electronics, handling and assembly (e.g. small part assembly), robotics and packaging
