TMP100: Digital Temperature Sensor with I2C Serial Interface

Features:

* DIGITAL OUTPUT: I2C Serial 2-Wire
* RESOLUTION: 9-to 12-Bits, User-Selectable
* ACCURACY:
±2.0°C from –25°C to +85°C (max)
±3.0°C from –55°C to +125°C (max)
* LOW QUIESCENT CURRENT: 45 µA, 0.1 µA Standby
* WIDE SUPPLY RANGE: 2.7V to 5.5V
* TINY SOT23-6 PACKAGE
* APPLICATIONS
o POWER-SUPPLY TEMPERATURE MONITORING
o COMPUTER PERIPHERAL THERMAL PROTECTION
o NOTEBOOK COMPUTERS
o CELL PHONES
o BATTERY MANAGEMENT
o OFFICE MACHINES
o THERMOSTAT CONTROLS
o ENVIRONMENTAL MONITORING and HVAC
o ELECTROMECHANICAL DEVICE TEMPERATURE

I2C is a trademark of NXP Semiconductors. All other trademarks are the property of their respective owners.

Description:

The TMP100 and TMP101 are two-wire, serial output temperature sensors available in SOT23-6 packages. Requiring no external components, the TMP100 and TMP101 are capable of reading temperatures with a resolution of 0.0625°C.

The TMP100 and TMP101 are ideal for extended temperature measurement in a variety of communication, computer, consumer, environmental, industrial, and instrumentation applications.

The TMP100 and TMP101 are specified for operation over a temperature range of –55°C to +125°C.
