Type 2 Photovoltaic Surge Protector : DPVN40CVGS series CITEL-2CP

Type 2 Photovoltaic Surge Protector : DPVN40CVGS series

Lightning arresters

Vote

“ Type 2 Photovoltaic Surge Protector CTC Technology VG Technology Remote signalling ”
Ask for a quote Receive Documentation Contact the supplier


The DPVN40CVGS is CITEL's new range of type 2 surge protectors designed to protect photovoltaic installations.

The development of these surge protectors is based on two technologies, patented exclusively by CITEL:
- VG Technology guarantees the total absence of leakage current and maximum product reliability.
- CTC Technology (Central Thermal Control), a completely new disconnection technology, incorporates a thermosensitive disconnection point placed in the centre of the SPD, guaranteeing the safest disconnection on the market.

The products are designed for DIN rail mounting. Compact and equipped with a fault indicator, these products facilitate installation and maintenance.

Type 2 PV surge protector CTC and VG technology Remote signaling Discharge current Imax/Itotal : 40/60 kA (8/20µs) IEC 61643-31, NF EN 61643-31, NF EN 50539-11 et UL1449 ed.5 compliance Common/Differential protection mode

Photovoltaic Solar fams Agrivoltaic
