Vortex flowmeter | Proline Prowirl F 200 / 7F2C

Vortex effect flow meter

Vote

“ - Easy energy management – integrated temperature and pressure measurement for steam and gases - Space-saving engineering – inlet run compensation - Same accuracy down to Re 10 000 – most linear Vortex meter body - Long-term stability – robust drift-free capacitive sensor - Convenient device wiring – separate connection compartment - Safe operation – no need to open the device due to display with touch control, background lighting - Integrated verification – Heartbeat Technology ”

Ask for a quote

Presentation

Versatile flowmeter with detection of wet steam conditions and best-in-class accuracy

Prowirl F is the multivariable flowmeter with inline wet steam measurement. Its calibration option PremiumCal guarantees excellent measuring accuracy and highest plant availability at low flow rates of gas, steam and liquids. With genuine loop-powered technology, Prowirl F 200 enables cost-effective and seamless integration into existing infrastructures. It offers highest operational safety in hazardous areas. Heartbeat Technology ensures process safety at all times.

Technical features

Measuring principle : Vortex Nominal diameter range : DN 15 to 300 (½ to 12'') Max. process pressure : PN 100, Class 600, 20K Medium temperature range : Standard: –40 to +260 °C (–40 to +500 °F) / High/low temperature (option): –200 to +400 °C (–328 to +752 °F) Outputs : 4‐20 mA HART (passive) 4‐20 mA (passive) / Pulse/frequency/switch output (passive) Inputs : Current Input 4‐20 mA (passive) Digital communication : HART, PROFIBUS PA, FOUNDATION Fieldbus Sensor housing material : Sensor connection housing: AlSi10Mg, coated; 1.4408 (CF3M) Transmitter housing material : AlSi10Mg, coated; 1.4404 (316L)

Download the complete technical features

Usage scope

Preferred measuring principle for wet/saturated/superheated steam, gases & liquids (also cryogenic) Suitable for a wide range of applications; optimized for steam applications Wet steam capabilities for DN 25 to 300 (1 to 12'') Robust dual-compartment housing Plant safety: worldwide approvals (SIL, Haz. area)
