Wireless 169 MHz M-Bus High Power N Mode RF Transceiver Module : Vulcanus EBV ELEKTRONIK

Wireless 169 MHz M-Bus High Power N Mode RF Transceiver Module : Vulcanus

Semi conductors and Modules for power factor correction

Vote

Ask for a quote

Presentation

The Vulcanus module measures only 15 x 34 x 3.8 mm and contains a communication engine with embedded Wireless M- Bus protocol software, a high performance RF transceiver and an amplifier.

The communication engine handles the radio packet protocol, the UART interface and controls the RF transceiver as well as the external IOs.

The external host processor will manage the module configuration by sending ‘AT’ commands to the communication engine via UART allowing configuring frequency, channels, output power, GPIO behavior etc.

The commands are used to start and stop the communication as well as to put the module in deep sleep to achieve ultra-low powerconsumption while the module is not used .

Some configuration parameters are stored in the internal non-volatile memory in order to be restored by a power-up sequence. The module has an advanced filtering circuitry to suppress harmonics and spurs.

Technical features

Embedded Wireless M-Bus protocol supporting EN 13757-4:2013 mode N Best in class Wireless M-Bus protocol stack High power, long range, up to +27 dBm Completely shielded GPIOs available for application Conforms with EU R&TTE directive (EN 300 220, EN 301 489, EN 60950) Configurable LBT as defined in CIG UNI/TS 11291-11-4 Hardware and software customization possible Configuration and RF communication by AT commands through UART
