Ammonium analyzer | Liquiline System CA80AM

Analyzers

Vote

“ - Fast commissioning and plug & play thanks to Memosens technology and user-friendly operation - Easy upgrade of functionality - even to a complete measuring station - simply by adding modules and connecting Memosens sensors - Advanced diagnostics with remote access for increased process safety - Reduced operating costs through automatic, configurable calibration and cleaning and long reagent shelf life with optional cooling module - Compliance with standard colorimetric measuring principle - indophenol blue method - following ISO 7150-1, DIN 38406-5 and GB 7481-87 ”

Ask for a quote

Presentation

Colorimetric system for online monitoring of water and wastewater treatment

Liquiline System CA80AM offers high-precision ammonium measurement in all critical control points. As member of the Liquiline platform, it enables plug & play and easy upgrade to a measuring station - minimizing the installation effort.

Automatic calibration and cleaning as well as the low consumption of reagents save you operating and maintenance costs. Advanced diagnostics with remote access ensure process safety and support you in providing process documentation to the authorities.

Technical features

Analyser Measuring Principle : Colorimetric Design : Open design / cabinet: Plastic ASA-PC - Stand housing: Plastic ASA-PC, steel coated Process temperature : 4 to 40 °C (39 to 104 °F) Ambient temperature : 5 to 40 °C (41 to 104 °F) Process pressure : Unpressurized Sample flow rate : Min. 5 ml/min (0.17 fl.oz/min) Power supply : 100 to 120 VAC / 200 to 240 VAC ± 10% / 24 VDC ± 10% / 50 ± 1 or 60 ± 1.2 Hz Input : 1 or 2 measuring channels / Optinonal 1 to 4 digital sensor inputs for sensors with Memosens protocol Measurement range : 0.05 to 20 mg/l NH4-N / 0.5 to 50 mg/l NH4-N / 1 to 100 mg/l NH4-N Output : 2x 0/4 to 20 mA Optional: Webserver, Modbus, Ethernet/IP, Profibus DP

Download the complete technical features

Usage scope

Inlets of wastewater treatment plants Outlets of wastewater treatment plants for documentation purposes Aeration basins Water treatment Cleaning capacity of municipal and industrial wastewater plants
