Combined CO2 and DO meter : CboxQC

Combined CO2 and DO meter : CboxQC - Anton Paar France

Combined CO2 and DO meter : CboxQC - Laboratory instruments

Combined CO2 and DO meter : CboxQC - produit présenté par Anton Paar France

Combined CO2 and DO meter : CboxQC

Laboratory instruments

“ Enjoy accurate results in 90 seconds - CO2 measurement method guarantees repeatability standard deviations of up to 0.005 vol. or 0.01 g/L (Standard version) - The new high-resolution optochemical O2 sensor is accurate and achieves a repeatability standard deviation of 2 ppb - Not influenced by other dissolved gasses such as air or nitrogen - Co2 and DO results after only 90 seconds - PFD filling device transfers samples from the package into the measuring chamber without any loss of CO2 - Low sample volume of around 100 mL (Standard version) provides reliable CO2 and DO results, even out of very small packages Get 11 hours of at-line use with our combined CO2 and DO meter - IP67 leakproof design lets you operate these in harsh, at-line environments - Integrated rechargeable battery - Compact, lightweight design - ideal for portable use Use built-in support for self-diagnosis and error detection - Intuitive user interface means easy menu navigation - Data logger function enables continuous CO2 and DO measurements from the line or the tank - FillingCheck automatically detects filling errors and generates a warning message - Guided system check function verifies the tightness of measuring chamber and the zero point of CO2 and O2 measurements Manage data in a traceable and convenient way - Clear sample identification for 500 traceable measurements results - RFID interface lets you make quick changes of measurements settings via RFID tag reading - Data is easily printed via Bluetooth or transferred to a PC via USB ”

Ask for a quote

Presentation

These combined CO2 and DO meters offer reliable quality control of finished packages, kegs, and casks as well as directly from the process line or tank. They guarantee fast and accurate determination of dissolved CO2 and O2 in beverages during producing and bottling. When combined with our filling devices, they let samples be taken directly from the package into the measuring chamber of the combined CO2 and DO meter, without losing dissolved CO2 during the sample transfer.

CboxQC At-line :

For measuring dissolved CO2 and O2 in the production environment
Sampling direclty from process lines, tanks, kegs, and casks
Protection class IP67 and rubber housing

CboxQC Standard :

For measuring dissolved CO2 and O2 in the laboratory
Reliable QC for finished packages as well as measurements in the lab
FillingCheck feature for automatic detection of filling errors

Technical features

Measuring range CO2 : 0 g/L to 12 g/L (0 vol. to 6 vol.) at 30 °C (86 °F) 0 g/L to 20 g/L (0 vol. to 10 vol.) <15 °C (59 °F) Measuring range O2 : 0 ppm to 4 ppm Measuring range Temperature : –3 °C to 40 °C (27 °F to 104 °F), acc. ±0.2 °C Measuring range Pressure : 0 bar to 10 bar absolute (0 psi to 145 psi), acc. 0.01 bar Repeatability s.d. : CO2 : ±0.01 g/L (0.005 vol.) Repeatability s.d. O2 : 2 ppb (in the range <200 ppb) Resolution CO2 : 0.001 g/L Resolution O2 : 0.1 ppb (in the range from 0 ppb to 99.9 ppb) Measuring units CO2 : g/L, vol., mg/L, kg/cm2, MPa, % w/w Measuring units O2 : ppm, ppb, hPa, mg/L, μg/L, % Air-sat., % O2-sat.

Download the complete technical features

Usage scope

Soft drinks Beer Wine Sparkling wine Sparkling water
