EN50155 & EN45545 Intel® Elkhart Lake Atom® x6425E Railway Computer | Nuvo-2615RL Series

Fanless PC

“ ‧ Compliant with EN 50155 mandatory tests and EN 45545-2 ‧ Rugged -40°C to 70°C fanless operations, compliant with EN 50155 Class OT4 ‧ 43V to 160V wide-range DC input with 1500Vdc insulation ‧ Intel® Elkhart Lake Atom® x6425E quad-core 2.0GHz/ 3.0GHz 12W processor ‧ 4x PoE+ GbE ports via M12 x-coded connectors ‧ Built-in SuperCAP UPS for power interruptions > 30 seconds (Nuvo-2615RL only) ‧ 1x front-accessible 2.5” 15mm HDD tray and 1x M.2 2280 SATA SSD ‧ 2x full-size mini-PCIe sockets and 1x M.2 3042/3052 B Key ”

Ask for a quote

Presentation

Nuvo-2615RL has a dedicated thermal design to meet EN50155 OT4 class (-40°C to 70°C) fanless operation with max CPU performance and up to 50W PoE+ delivery. To overcome the challenging railway conditions, from voltage fluctuations to power outage interruptions, Nuvo-2615RL is equipped with an isolated wide 43V to 160V DC input design and a built-in SuperCAP UPS to sustain more than 30 seconds of operation time without power supply. If power outage time exceeds the sustainable duration, the internal microcontroller (MCU) will trigger a software shutdown before running out of SuperCAP energy to protect the hardware, data, and minimize maintenance costs.

Integrating an Intel Atom® quad-core x6425E, -40°C to 70°C fanless operations, M12 PoE+ connectivity, up to 5TB data storage capacity, 2500 watt second SuperCAP UPS, 43V to 160V wide-range DC input, and EN50155 and EN45545 compliance, the Nuvo-2615RL series is the ideal rugged transportation computer for vision-based rolling stock applications.
