IKEUCHI EUROPE B.V.

GSIM series – Full cone spray nozzle Pneumatic Spray Nozzles – All Spray Pattern IKEUCHI EUROPE B.V.

GSIM series – Full cone spray nozzle Pneumatic Spray Nozzles – All Spray Pattern

Vote

Ask for a quote Receive Documentation Contact the supplier


Features
  • Full cone pneumatic spray nozzle producing a large amount of “fine fog”.
  • Energy-saving design – mean droplet diameter of 50 μm and a maximum droplet diameter of 150 μm (*4) at an air-water ratio of 130.
  • Large turn-down ratio.
  • Spray angle of 20° or 60°.


Applications
  • Cooling: Gas, moldings, refractories
  • Moisture control: Gas, concrete
  • Combustion: Oil, waste fluid
  • Dust suppression: Recycling facilities, material facilities, moldings

Pipe conn. :size Liquid inlet: Rc 3/8 Spray angle : 20°, 60° Spray capacity : 15 - 2,000 ℓ/hr Supply air type : Compressed air Liquid feeding system: Liquid pressure Mean droplet diameter : 30 - 80 μm Air consumption : 150 - 4,000 ℓ/min, Normal Free passage diameter :1.8 - 4.0 mm
Download the complete technical features

Iron and steel making Pollution control Dust control in factory FGD solution for Sox reduction
