SOCIÉTÉ NOUVELLE SOCOPRESSES

Hydraulic presses for forming, punching, pressing, cutting and assembly

Hydraulic presses for forming, punching, pressing, cutting and assembly - SOCIÉTÉ NOUVELLE SOCOPRESSES

Hydraulic presses for forming, punching, pressing, cutting and assembly - Hydraulic presses

Hydraulic presses for forming, punching, pressing, cutting and assembly

Hydraulic presses

“ - High power, up to 600 T - Long travel and high speed - Made to measure ”

Ask for a quote

Presentation

Force: Max: 6000 kN Min: 100 kN
Stroke: 200 mm, 350 mm, 500 mm
Opening: Max: 1000 mm, Min: 50mm
Press speed: Max: 40 mm/s Min: 17 mm/s
Hydraulic pump power: 5.5 kW; 7.5 kW; 11 kW; 15 kW; 22 kW
Return speed: 215 mm/s, 230 mm/s, 240 mm/s, 300 mm/s
Placement speed: 200 mm/s, 220 mm/s, 280 mm/s, 290 mm/s, 370 mm/s

Our machines are designed to make the most of your production programs. They are custom-built according to your needs

Our products are designed to meet the most demanding conditions of use, including high production rates, 24 hours a day, 7 days a week.

As we are aware of MSDs (musculoskeletal disorders), we can work with you to optimize workstation ergonomics.

Options include
- A cycle start function based on the occultation of the light curtain (the safety module is programmed to manage the "cycle start" function);
- a measuring chain for recording force curves (force vs. displacement). This configuration provides excellent visibility of the assembly process.
- a brushless motor-pump unit to stop the press at any idle time, thus saving energy.

Translated with DeepL.com (free version)

Technical features

Functions: forming, punching, compression, cutting, assembly Control: semi-automatic, PLC-controlled Force : Max: 6 000 kN Min: 100 kN Opening: Max: 1 000 mm, Min: 50 mm (2 in), other on request Strokes: 200 mm, 350 mm, 500 mm Press speed: Max: 40 mm/s Min: 17 mm/s Return speed: 215 mm/s, 230 mm/s, 240 mm/s, 300 mm/s Placement speeds: 200 mm/s, 220 mm/s, 280 mm/s, 290 mm/s, 370 mm/s Hydraulic pump power: 5.5 kW, 7.5 kW, 11 kW, 15 kW, 22 kW
