Inogun M Manual powder gun SAMES KREMLIN

Inogun M Manual powder gun

Spray guns

Vote

“ USER-FRIENDLY AND ERGONOMIC MANUAL POWDER GUN - Lifetime finish quality: Long life cascade durability and HV performance - Efficient powder transfer: TEC5 technology - Balanced and ergonomic design: No repetitive strain damage, less fatigue ”
Contact the supplier Receive Documentation Ask for a quote

The Inogun M is designed to provide the best quality powder application because it is well-balanced, supplied with low voltage cable, powder tube and reactive trigger that requires a gentle touch. The powerful high voltage unit coupled with the high voltage control unit provides a high wraparound effect on large parts (D. 500mm / 20 in) and has deep penetration into recessed areas. This reduces the cost of the equipment with a better powder usage rate and reduces the time to spray the powder.

The Inogun M is controlled by the Inobox which has a clear and easy to use interface. The connected integrated Inocontroller can also be used when it is necessary to integrate an automatic booth. The Inobox and the Inocontroller are the main control centers for manual and automatic applications as it performs high voltage and all air controls: current, electrode cleaning air, injection, and dilution. Dust and energy saving has been implemented at the heart of the gun to reduce waste, and increase productivity and the quality of finishing powder. TEC5 (Transfer Electronic Control) technology provides electrostatic charge self-adjustment, taking into account powder flow and part distance, to optimize powder transfer efficiency and finish quality.

The Inogun M is available in different kits according to the needs of your powder coating process. The Inogun M can be used as a main applicator to perform powder coating and can be mounted on a tank or independent powder supply box on a vibrating table. The Inogun M can be used as a pre-touch or touch-up solution in an automatic booth to obtain the desired coating on the workpiece. The Inogun M is also used for non-destructive testing applications

Maximum air pressure : 7 bar / 101.5 psi Air consumption : 2 - 10 m3/h / 1.2 - 5.9 cfm High voltage (maximum) : 100 kV Current max : 110 µA Relative humidity max : 80% Height : 265 mm / 10.4 in Width : 52 mm / 2 in Length (gun only) : 340 mm / 13.4 in Weight : 549 g / 19.4 oz
Download the complete technical features
