Laminator for Adhesive Products with Slitting and Rewinding Systems : FEBA - Laminator DOREY

Laminator for Adhesive Products with Slitting and Rewinding Systems : FEBA - Laminator

Pipe cutting machine

Vote

Ask for a quote Receive Documentation Contact the supplier

F.E.B.A. Laminating System is suitable for laminating, slitting and rewinding heat-activated or cold-bond adhesive products to fabrics, foam/rubber, soft foam, cork, felt and similar materials. Standard and special machines available to suit the customers specific converting application.

UNWIND UNIT
  • The unwind unit is composed of one station for the axial unwinding of the master logs. Manual web guide left and right.
  • One 3" removable pneumatic shaft and brake.
DRAWING UNITS
  • The first drawing unit is composed of two large diameter siliconized rubber covered rolls; suitable for the unwinding of high and low thickness foam rolls.
  • The second drawing unit is composed of two large diameter siliconized rubber covered rolls and will be equipped with a separate brake and clutch to be used when laminating very thin elastic materials or slitting narrow widths.
UPPER UNWIND
  • The upper unwind is to keep the single sided tape to be transferred. Manual web guide left & right.
  • The unit is composed of a 3" removable pneumatic shaft and brake.
LOWER UNWIND
  • The lower unwind is to keep the single sided tape to be transferred. Manual web guide left & right.
  • This unit is fitted on a removable trolley and fixed with pins.
  • The unit is composed of a 3” removable pneumatic shaft and brake.
HEATING UNIT
  • The heating unit is equipped with three individual infrared lamps with temperatures ranging from 0-700 degrees Fahrenheit, which is ideal when laminating heat-activated adhesives.
SLITTING UNIT
  • One heavy-duty scissor cut slitting unit with 120MM OD blades and counter-blades. (Minimum Slit Width of 2")
REWIND UNIT
  • The rewind unit is driven and is composed of one station for the axial unwinding of the master logs. Switch for rewinding CW or CCW.
  • Tension adjustment for precise tension control.
  • One 3" removable pneumatic shaft.




Maximum Material Width : 1600MM (63 Maximum OD of Master Jumbo Roll : 1200MM Material Thickness : 2-30MM Maximum OD of PSA : 500MM Core Inside Diameter : 3 Maximum Output Speed : Up to 35M/Min. Maximum OD of Rewound Roll : 1200MM
