This type of stainless steel low profile compression load cell is particularly suitable for silos weighing.Various models of mounting kits are available for a fast and simple integration under silos’ feet, machine, hopper…
R10 compression load cell characteristics :
• Measuring capacity (weighing) from 1 to 100 tons
• IP68 Protection rating
• Accuracy up to ± 0.05%.
• Grain of spherical supports for centering the load on the load cell.
R10 compression load cell options :
• Compression mounting kit
• Compression mouting kit with anti-lifting device
• ATEX version (explosive zone)
R10 load cell electrical characteristics :
• Supply voltage range: 1 to 15 V
• Compensated temperature range : -10 … +50 C°
• Protection rating: IP68 according EN 60529
• Temperature range : -20 … +60 C°
• Material : Stainless steel
• Cable length : 10m
• Load cell net weight : 1,5 (≤ 15 t)/4 (30 t et 50 t-S)/10 (≥ 50 t) kg
