Machine Elements EH 2505 HALDER FRANCE SAS

Machine Elements EH 2505

Assembly systems and components

Vote

Ask for a quote Receive Documentation Contact the supplier

Note:

It is a self-centering and non-floating tapered shaft hub in corrosion-protected design with a hexagon nut. By using tapered shaft hubs, all shaft-hub joints of machine elements such as sprocket wheels, gear wheels, belt pulleys, cams, levers etc. can be easily and efficiently established.

Mounting instructions, mounting arrangements and technical data will be found on the following pages.

TA = Tightening torque of nut, M = Transferable torque, Fa = Transferable thrust load
pW = Surface pressure shaft, pN = Surface pressure hub.

The rotational accuracy is 0,03 mm.

Material:

Inner part:

  • Steel, nickel-platedExternal part:
  • Steel, galvanizedNut:
  • Steel, nickel-plated
