Magnetically levitated turbo-molecular pump : STP-iXR2206 ISO250F EDWARDS SAS

Magnetically levitated turbo-molecular pump : STP-iXR2206 ISO250F

Vacuum pump

Vote

Ask for a quote Receive Documentation Contact the supplier

STP-iXR2206 series magnetically levitated turbo-molecular pump provides industry-leading performance and incorporates latest technology small power supply into the on-board control which is the same concept with STP-iXA2206/iXA3306 series.

The pumping performance is improved by the newest developed revolutionary rotor design. This fully integrated product offers easy installation and small footprint as an all-in-one solution for all application tools.

Allowable backing pressure : 266 Pa (2 Torr) Rated speed : 36,500 rpm Starting time : ≦10 min Mounting position : Any orientation Cooling method : Water cooling Lubricating oil : Not necessary Ambient temperature range : 0 to 40 °C Storage temperature range : -5 to 55 °C Input voltage : 200 to 240 (± 10) V a.c. Maximum input power : 750 VA
Download the complete technical features

Drop your rating on Magnetically levitated turbo-molecular pump : STP-iXR2206 ISO250F

Your answer to the rating from -

OTHER PRODUCTS VACUUM PUMP FROM EDWARDS SAS

Dry scroll pump 1ph 50/60 Hz : nXDS20i

Dry scroll pump 1ph 50/60 Hz : nXDS20i

 Ask for a quote
Scroll Pumps : nXDS6iC

Scroll Pumps : nXDS6iC

Ask for a quote
Medium and Large Dry Pumps and Systems : GXS160, 200 - 230 V, Light Duty, Side Exhaust
