Medium and Large Dry Pumps and Systems : Drystar 80/EH500 SSP & Silencer 380-415V 50Hz EDWARDS SAS

Medium and Large Dry Pumps and Systems : Drystar 80/EH500 SSP & Silencer 380-415V 50Hz

Vacuum pump

Vote

Ask for a quote Receive Documentation Contact the supplier

Drystar80 is the most cost effective introduction to basic dry pumping. It is available as a stand-alone unit for 80 m3h-1 repeatable pumping performance; or in a combination with the respected EH500 hydrokinetic drive mechanical booster, offering 500 m3h-1 displacement for applications where increased pumping speed and/or lower vacuum levels are required. Depending upon the application the Drystar80 can be supplied with mineral oil or PFPE lubrication.

Peak Pumping Speed 50 Hz : 390 m3h-1 (230 cfm) Peak Pumping Speed 60 Hz : 471 m3h-1 (277 cfm) Power @ ultimate pressure : 4.3 kW Motor Power : 6.6 kW Electrical supply : 200-230V 3Æ 50/60Hz or 380-460V 3Æ 50/60Hz Inlet connection : ISO100 Outlet connection : NW40 Cooling method : Water/Air Max cooling Water supply pressure : 8 bar (116 psig) Cooling Water DP across pump : 2.1 bar (30 psig)
Download the complete technical features
