Paint Pump Airmix® 20C50 30C25 SAMES KREMLIN

Paint Pump Airmix® 20C50 30C25

Paint pumps and paint application products

Vote

“ The 30C25 compact Airmix® paint pump is recommended to handle all types of materials ranging from low to medium viscosity. ”

Ask for a quote

Presentation

This compact Airmix® paint pump is the ideal partner for your Airmix® spray guns providing exceptional finish quality & high transfer efficiency.

Efficiency - perfect for Airmix® finish
Optimization - built with minimal parts
Simplicity - lowest cost of ownership

Performance

Constant and pulse-free delivery for superior finish
Priming at very low air pressures (0.6 bar)

Productivity

Large foot valve to handle high viscosity materials (up to 5,000 cPs)
A closed construction prevents risk of injuries & protects lubricant from external contamination
Easy, rotatable outlet fitting for quick maintenance
Designed to eliminate dead zones and facilitate pump priming & flushing
Leak monitoring vent hole for fast control
Quiet air motor - low noise

Sustainability

Air motor (45% less spare parts vs competitors for maintenance)
Differential air motor keeps paint pump from frosting over
Ultra coated plugger for less friction & improved abrasion resistance
Single GT seal to avoid throat packing maintenance & low friction, large lubricant wet cup

Technical features

Pressure Ratio : 30/1 Maximum Fluid Pressure : 180 (2610) bar (psi) Maximum Air Pressure : 6 (87) bar (psi) Air Consumption : 7.1 (4.18) m³/h (cfm) Weight : 7.7 (17) kg (lbs) Cylinder : 25 (0.84) cc (oz) Weighted Sound Level : 74.9 dBA Recommended Air Pressure : 2 - 5 (29 - 72.5) bar (psi) Fluid Output at 30 cycles/mn: 0.75 (0.2) l/min (gal/mn) Fluid Output at 20 cycles/mn : 0.5 (0.13) l/mn (gal/mn)
