Pressurized painting booths with dry filtration

Paint booth

Ask for a quote

Range for car body with vertical airflow.

Optional accessories

Waterproof neon light, 1200 mm length, IP 65, 2 neon 36 W (1 lamp each 2 m of cabin length).
Raised metallic base, h = 300 mm with access ramp.
Differential manometer.
Electrical control board.

Notes

Technical characteristics and dimensions are given as indication and open to improvement.
Civil engineering is left to the customer’s care: 2 canals wideness 600 mm and depth 700 mm with a linking channel to the sucking unit.
Carried out in galvanized metal sheet, in pre-painted galvanized metal sheet, and painted steel.
Thickness of the insulating panels 50 mm.
Useful dimensions main gate mm: 3000 x 2500 h.
Pedestrian door dimensions mm: 1000 x 2500 h.
Heater with heat exchanger air/combustion fumes. Burners gas and/or gas oil.
Temperature in painting phase 18°C, in oven phase 60°C.
Filtration under grid with filter in glass fibre, filtration aspirant unit in synthetic fabric.
Spare parts supplied in kit.
