Wire-wound potentiometer - MUP MEGATRON Elektronik GmbH & Co. KG

Wire-wound potentiometer - MUP

Potentiometers

Vote

Ask for a quote Receive Documentation Contact the supplier

The MUP potentiometers in 22 mm housing are suitable for applications where a compact sensor with good quality at a reasonable price is important.
The precision potentiometers of the MUP series are space-saving, economical and universal wirewound potentiometers. Models are available with an electrical rotation angle of 320° (MUP1300 / 1350) and 270° (MUP1307).

Economical and universal potentiometer
Compact with only 8.6 mm housing depth
With mechanical end stop (320° / 270°)
Power-saving in compact mobile applications
A potentiometer with many options
Options:

Front shaft sealing
Front shaft adjustment
Back shaft
Center tap
Screwdriver slot
Tandem Version
We offer many adaptations on request: Multi ganged potentiometers, with increased torque for manual operation, sealed housing case, special electrical and mechanical angles of rotation, and special resistance and linearity tolerances. Furthermore, we can mount gear wheels or attach cable assemblies with or without connectors and much more. Please use our request form and describe your application, so we can determine the optimal product for your design-in.

Configuration: single-turn Operation: manual Technology: wire-wound Other characteristics: precision,for industrial applications,wire-wound Operating temperature range: -30 °C up to +105 °C Storage temperature range: -30 °C up to +105 °C Protection grade (IEC 60529): IP40 Housing diameter: 22 mm Housing depth: 8.6 mm Shaft diameter: 6 mm
Download the complete technical features
