15C25 Airmix® Paint Pump

Paint pumps and paint application products

Vote

“ The 15C25 Compact Airmix® paint pump is recommended to handle all types of materials, ranging from medium to low viscosity. ”

Ask for a quote

Presentation

The compact Airmix® painting pump is the ideal partner for your Airmix® spray guns, providing exceptional finish quality & high transfer efficiency.

Efficiency: perfect for Airmix® finish
Optimization: built with minimal parts
Simplicity: lowest cost of ownership

PERFORMANCE

Constant delivery and pulse free for superior finish
Priming at very low air pressure (0.6 bar)

PRODUCTIVITY

Large foot valve to handle high viscosity materials up to 5,000 cPs
A closed construction to prevent from risk of injuries & to protect lubricant from external contamination
Quick maintenance thanks to an easy rotable outlet fitting
Facilitate pump priming & flushing thanks to a design made to eliminate dead zone: time saved
Leak monitoring vent hole for fast control
A quiet air motor make very low noise

SUSTAINABILITY

45% less part vs competitors for the air motor to provide a better maintenance
Differential air motor to avoid the paint pump from frost
Ultra coated pluger for less friction & improved abrasion resistance
Single GT seal to avoid throat packing maintenance & low friction & offers a large lubricant wet cup

Technical features

Pressure Ratio : 15/1 Maximum Fluid Pressure: 90 (1305) bar (psi) Maximum Air Pressure : 6 (87) bar (psi) Air Consumption 2.8 (1.65): m³/h (cfm) Weight: 7.7 (17) kg (lbs) Maximum Temperature : 60 (140) °C (°F) Cylinder : 25 (0.84) cc (oz) Weighted Sound Level: 71.2 dBA Recommended Air Pressure : 2 - 5 (29 - 72.5) bar (psi) Fluid Output at 30 cycles/mn: 0.75 (0.2) l/min (gal/mn)

Download the complete technical features
