Direct Drive PSD 43 halstrup-walcher GmbH

Direct Drive PSD 43

Positioners and Tightening components

Vote

Ask for a quote Receive Documentation Contact the supplier

PSD 43 direct drive is a mechatronic system with integrated control, bus interface and absolute measurement system without battery. This drive is ideal for automatic format changeover. The stepper motor with integrated control and bus communication permits higher velocities at lower torques.
The PSD can be easily addressed by rotary switches (not for IO-Link). The instruments can be mounted on a spindle using the hollow shaft without the need for an additional coupling. The optional rotatable attachment housing allows you to attach the direct drives to the machine in any position, no angle plugs are required.

Nominal torque / nominal rated speed: 2 .. 8 Nm / 200 .. 50 rpm Positioning range: 977 .. 4026 rotations Protection class: IP 50 or IP 65 Design: Horizontal construction, Nema 23, space-saving, compact design Output shaft: 8 mm solid shaft with flattening or 8 / 14 mm hollow shaft with torque support Data interface: CANopen, IO-Link, PROFINET, EtherCAT, EtherNet / IP Special features: Precise position feedback thanks to an absolute measurement system without battery Special features: Address may be set using the bus or an address switch (not for IO-Link)
Download the complete technical features
