Electromagnetic flowmeter | Proline Promag P 300 Endress+Hauser France

Electromagnetic flowmeter | Proline Promag P 300

Electromagnetic flow meter

Vote

“ - Diverse applications – wide variety of wetted materials - Energy-saving flow measurement – no pressure loss due to cross-section constriction - Maintenance-free – no moving parts - Full access to process and diagnostic information – numerous, freely combinable I/Os and fieldbuses - Reduced complexity and variety – freely configurable I/O functionality - Integrated verification – Heartbeat Technology ”
Go to the supplier’s website Receive Documentation Ask for a quote


High-temperature flowmeter for process applications with a compact, easily accessible transmitter

Promag P is dedicated to chemical and process applications with corrosive liquids and highest medium temperatures. With its compact transmitter Promag P 300 offers a high flexibility in terms of operation and system integration: access from one side, remote display and improved connectivity options.

Heartbeat Technology ensures compliance and process safety at all times.

Measuring Principle : Electromagnetic Nominal diameter range DN 15 to 600 (½ to 24'') Measured variables : Volume flow, conductivity, mass flow Measuring range : 4 dm³/min to 9600 m³/h (1 gal/min to 44 000 gal/min) Max. process pressure : PN 40, Class 300, 20K Transmitter housing material : AlSi10Mg, coated; 1.4409 (CF3M) similar to 316L; stainless steel for hygenic transmitter design Degree of protection : Standard: IP66/67, Type 4X enclosure / Option: IP69 Inputs : Status input 4-20 mA input Outputs : 3 outputs: 4-20 mA HART (active/passive), 4-20 mA WirelessHART 4-20 mA (active/passive),Pulse/frequency/switch output (active/passive), Double pulse output (active/passive), Relay output Digital communication : HART, PROFIBUS DP, PROFIBUS PA, FOUNDATION Fieldbus, Modbus RS485, Profinet, Ethernet/IP, OPC-UA
Download the complete technical features

The bidirectional measuring principle is virtually independent of pressure, density, temperature and viscosity Dedicated to chemical and process applications with corrosive liquids and high medium temperatures
