Electromagnetic flowmeter | Proline Promag P 200

Electromagnetic flow meter

Vote

“ - Versatile applications – wide variety of wetted materials - Energy-saving flow measurement – no pressure loss due to cross-section constriction - Maintenance-free – no moving parts - Convenient device wiring – separate connection compartment - Safe operation – no need to open the device due to display with touch control, background lighting - Integrated verification – Heartbeat Technology ”

Ask for a quote

Presentation

The flowmeter for highest medium temperatures with genuine loop-powered technology

Promag P is dedicated to chemical and process applications with corrosive liquids and high medium temperatures.

With genuine loop-powered technology, Promag P 200 enables cost-effective and seamless integration into existing infrastructures. It offers highest operational safety in hazardous areas thanks to its intrinsically safe design (Ex ia). Heartbeat Technology ensures process safety at all times.

Technical features

Measuring Principle : Electromagnetic Nominal diameter range DN 15 to 200 (½ to 8'') Measured variables : Volume flow, mass flow Measuring range : 4 dm3/min to 1100 m3/h (1 to 4850 gal/min) Max. process pressure : PN 40, Class 300, 20K Degree of protection : IP66/67, type 4X enclosure Outputs : 4‐20 mA HART (passive) Pulse/frequency/switch output (passive) Input : None Digital communication : HART, PROFIBUS PA, FOUNDATION Fieldbus Power supply : DC 18 to 35 V (4‐20 mA HART with/without pulse/frequency/switch output)

Download the complete technical features

Usage scope

The bidirectional measuring principle is virtually independent of pressure, density, temperature and viscosity Dedicated to chemical and process applications with corrosive liquids and high medium temperatures

Opinion on the product
