Hanheld Thermography camera CX200+

Thermal infrared cameras

“ - resolution 256x192 pixels 12µm pitch - NETD 40mK - scene temperature -20 to +150°C and 100 to +550°C - robust (IP54) and long battery life (15 hours) - low weight ”

Ask for a quote

Raythink's CX200+ portable thermography camera offers 256 x 192 pixel resolution with 12µm pitch and 40mK NETD for a temperature range from -20 to 550°C.
It's an ideal solution for first-level preventive and predictive maintenance in the electrical, mechanical, air-conditioning/heating and refrigeration sectors, as well as in automotive garages. It is available in three versions: C200SE+ (thermal only), CX200+ and CX200 Pro+ (thermal and visible).

Featuring a 2.8" (7.1cm) LCD touchscreen with 320 × 240 pixel resolution and a frame rate of 25 Hz, this camera enables automatic hot and cold spot tracking or image alarm generation via threshold.
Operational within 6 seconds of start-up, weighing just 520 grams, the CX200+ can display, record and transmit images or videos. Numerous real-time image processing options are available in the software (color palette, 2 and 4X digital zoom, visible/IR image fusion, image-in-image, etc.).

Its built-in battery can be recharged in 4 hours, providing a long runtime of at least 15 hours.
Its IP54-rated casing withstands drops of up to 2 m, ensuring that users have a robust, versatile tool in hand... The CX200+ can also be mounted on a tripod, thanks to its standard 1/4" interface on the bottom of the handle.

It comes complete with USB cable, 32GB SD memory, user manual, storage bag and quality and calibration certificates.

Technical features

Resolution 256x192 pixels 12µm pitch VoX NETD 40mK microbolometer Scene temperature -20°C to +150°C and +100°C to +550°C Operating temperature -10°C to +50°C Display 2.8 inches (7cm) Low weight 520 grams 32GB SD card (expandable to 128GB)

Download the complete technical features
