High-frequency generator Z82 BS MED

Manual bag sealing machines

Vote

Ask for a quote

Presentation

The safe and practical alternative for systems for packaging solutes in glass or plastic flasks.

HEALTHCARE SAFETY
Sterility is preserved because no air needs to be added
(sterilisation at 121°c).
PRACTICAL
Ultra-resistant for handling for medical work inside or outside
hospitals, easy to attach...
REDUCED STORAGE SPACE
Vacuum packages require minimal storage space, unlike rigid packages.

Medical : blood transfusion bags, bags for standard solutions (chloride, dextrose, glucose), dialysis, drainage…

OPTIONS :

Z82 BS GANTRY PRESS - 4 COLUMNS
- Control by cylinder or motor:
- Hydraulic up to 4000 daN
- Traceability of sealing data
- integration into Thimonnier’s automatic production line
- Stamping of medical bags
- Recognition cells for positioning film
- Punching of suspension holes
- Automatic sheller

UPPER TABLE WITH HF SHIELDING
- Electrical heating or hydraulic climate control

Technical features

Power supply: 400 V Tri. + N - 50 Hz Compressed air supply: Input pressure = 7 - 9 bar Effective pressure = 6 bar - Output: Q = 30 Nm3/h Sealing area 50 to 500 cm² Cooling water = 80 litres/h

Download the complete technical features
