Industrial Ethernet Switch | 7506GX2

Remote Monitoring Options - For ease of confi guration and monitoring, the 7506GX2 offers web browser management and N-View OLE for process control (OPC) server software.

The N-TRON N-View software can be combined with popular HMI software packages to add network traffi c monitoring, trending, and alarming to any application using N-TRON switches.  In addition, SNMP is available for switch link and status monitoring.

The status LED can be confi gured to respond to power failure on power input 1 or input 2, N-Link fault, port usage fault, N-Ring broken, partial break high, partial break low, or if multiple ring managers are detected. N-Ring Technology - N-TRON's 7506GX2 ring manager using N-TRON's N-Ringtechnology offers expanded ring size capacity, detailed fault diagnostics, and a standard healing time of ~30ms.

The 7506GX2 ring manager periodically checks the health of the ring via heart beat packets.  If the ring manager stops receiving these health check packets, it converts the ring to a linear topology within ~30ms.

When all switches in the ring are N-TRON fully managed switches, a detailed ring map and fault location chart will also be provided on the ring manager’s web browser and OPC server to identify the health status of the ring.  N-Link™ allows the linking of two N-Rings.

Up to 250 fully managed N-TRONswitches can participate in N-Ringtopologies. Industrial Packaging and Specifi cations - The 7506GX2 is designed to operate in industrial environments.

It is housed in a rugged extruded aluminum DIN-Rail enclosure.  It has extended industrial specifi cations and features to meet or exceed the operating parameters of connected equipment.

These include extended temperature ratings, extended shock and vibration specs, redundant power inputs, and high MTBF (greater than 2M hours). Ease of Use - The 10/100/1000BaseT(X) ports are auto sensing and auto confi guring.

Each copper port is automatically negotiated for maximum speed and performance by default, but can also be hard coded through the user interface.  A high speed processor allows wire speed capability on all 10/100/1000BaseT(X) ports simultaneously.  PRODUCT
