Modula Lift

Dynamic storage

Vote

“ The best automated warehouse system to recover space and increase security ”

Ask for a quote

Presentation

Since its introduction to the market over 30 years ago, the Modula vertical lift system is among the most reliable and advanced storage systems available today.

Technical Data
The Modula vertical lift system is the ideal solution to store any industrial products, components or spare parts in all possible industrial environments, industries and departments.

Many companies have chosen a Modula storage system to reorganize and improve workflow due to its flexibility, the wide range of models, the overall design and ease of use.

Software can be used with a Modula vertical storage system or as a stand-alone system that manages all possible warehouse operations or, a combination of both. To gain the most benefit from your Modula and increase your productivity, we offer a wide range of accessories.

Modula Lift is available in the followings models:

• MA & MA-D

• MC & MC-D

• MX & MX-D

• ML & ML-D

• ME & ME-D

Technical features

UNIT HEIGHTS from 3.300 mm to 16.100 mm UNIT HEIGHT INCREMENT 200 mm TRAY STORAGE PITCH 25 mm TRAY WIDTHS from 1.500 mm to 4.100 mm TRAY DEPTHS 654 mm & 857 mm GROSS TOTAL PAYLOAD from 35.000 kg to 90.000 kg depending on model and configuration MAXIMUM STACKABLE HEIGHT 695 mm (bay S) / 895 mm (bay M) / 1,295 mm (bay XL) THROUGHPUT up to 120 trays/hr (depending on the configuration) OPERATOR INTERFACE industrial console with 10.4’ ’touch screen (Copilot) NUMBER OF BAYS up to 3, also above ground level and on the same side
