MODULA SLIM

Dynamic storage

Vote

“ • It reduces floor space by maximizing storage density • It reduces your picking times as much as possible • It allows all operators to access materials quickly and ergonomically • It allows to control stocks and all store figures • It easily integrates into your business process by communicating with all ERP systems • It traces the picking operations by identifying the person who performs them and controlling all access • It reduces sampling and deposit errors to zero by guiding the operator ”

Ask for a quote

Presentation

Modula Slim is the smart choice for anyone looking for a totally flexible vertical storage solution.

Technical Data

You can store all sorts of materials and products in your Modula Slim vertical storage system: loose materials, containers (boxes, bins, packs, cartons, cases), small items, spare parts, coils, flasks.

All the advantages of Lift technology built into:
• 3 sq.m of floor space

What Modula Slim can do for you?

• Recover floor space, making the most of storage density
• Reduce picking times
• Make materials accessible to all operators, quickly and ergonomically
• Keep stock levels and all storage system items under control
• Integrate easily into your company processes by communicating with all ERP systems
• Track picking and refilling operations, identifying who did what and control every access
• Eliminate picking and refilling errors by guiding the operator through the process

Make use of all the space inside your Modula Slim without limits or constraints

• Total payload is up to 25,000 kg with up to 7 metres in height and no more than 1.6 m in depth
• You can make use of all the availabe space in your vertical storage system thanks to dynamic tray height storage: there are no fixed heights, as the Modula Slim calculates the best place to put the trays and eliminates any wasted space between them
• Unlike in a vertical storage carousel, with Lift technology and the way the elevator moves, there are no issues with unbalanced loads
• Energy consumption is relatively low: less than 1.2 kW/h
• You can choose to power the lift system with a three-phase (400V) or a single-phase (230V) supply
• Maintenance requirements are reduced: the V-Shape toothed belt transmission system is super quiet, requires no lubrication and its self-aligning pulley system means it’s super easy to install and adjust
• You can add all available options from the Modula vertical storage solutions range, such as visual aids, put to light, access control systems, partitions, dividers and slotted tray walls to subdivide the trays

Technical features

3 m2 of floor space 1,6 m depth INTEGRATED ERGONOMIC TOUCH SCREEN INTERFACE V-SHAPE STEEL REINFORCED TOOTHED BELT Up to 7 meters Unit height: from 2.400 mm to 7.000 mm Unit height increment: 100 mm Tray storage pitch: 25 mm Tray widths: 1.300 - 1.900 - 2.500 mm Tray depth: 425 mm
