Paint Circulating System Pump : PCS 03R440 Airspray Flowmax® SAMES KREMLIN

Paint Circulating System Pump : PCS 03R440 Airspray Flowmax®

Paint pumps and paint application products

Vote

“ The piston is continuously cleaned with pressurized lubricant. This extends the life cycle of the pump and reduces maintenance. ”
Ask for a quote Receive Documentation Contact the supplier

The new PCS "R" range was designed to solve common issues of 24/7 paint circulating systems. The PCS "R" pumps feature Bellows technology and a state of the art lubricant circulating system.
  •     Extended lifetime
  •     Quick and simple maintenance
  •     Clean paint kitchen

 PERFORMANCE
  •     2 sizes of air motors to deliver the product at the right pressure for high quality finish while reducing air consumption
  •     The pump piston is continuously cleaned with pressurized lubricant. This extends the life cycle of the pump and reduces maintenance
  •     The PCS 03-R440 is a powerful and robust pump that's “best in class” for endurance and fast and easy maintenance

PRODUCTIVITY
  •     Quick and easy maintenance operation due to the divorced design of the fluid section
  •     Anticipate maintenance operations - visual checking the leak detector or any lubricant color change
  •     Wall-mounted air motor design allows easy removal of only the fluid section
  •     Optimized space in the paint kitchen

SUSTAINABILITY
  •     Increased lifetime due to the permanent circulation of the lubricant under pressure allowing active cleaning of any particles sticking on the piston
  •     Extended lifetime - up to 10,000,000 cycles - due to the use of the SAMES KREMLIN Bellows instead of a lubricant cup
  •     Always clean paint kitchen environment - Bellows prevents any leakage outside the fluid section
  •     Optimum wear resistance stainless steel, triple chrome and tungsten carbide construction

Pressure Ratio : 3:1 Maximum Fluid Pressure: 18 (260.9) bar (psi) Maximum Air Pressure : 6 (87) bar (psi) Weight: 52.8 (116.4) kg (lbs) Maximum Temperature : 50 (122) °C (°F) Cylinder : 440 (14.9) cc (oz) Sound Level: 68.4 dBa Fluid Output at 20 cycles/mn : 8.8 (2.3) l/mn (gal/mn) Free Flow Rate : 26.4 (7) l/mn (gal/mn) Air Inlet : F 3/4
Download the complete technical features
