REXSON SH0910 Shovel pump SAMES KREMLIN

REXSON SH0910 Shovel pump

Paint pumps and paint application products

Vote

“ PUMPING BEYOND POSSIBLE. - Robust and reliable - Simple to maintain - Configurable and versatile ”
Ask for a quote Receive Documentation Contact the supplier

The REXSON pumps of the  high viscosity  range have been designed with robustness in mind, and the aim of offering a high degree of modularity to follow your application. Unlike liquid fluid pumping, the high viscosity range imposes highly variable mechanical stresses from one product to another.

Double-acting shovel pumps are specifically designed to transfer fluid with a viscosity greater than 50,000 Cps and operate from 25,000 Cps for products whose particular rheology makes them difficult to pump. These pumps include a shovel that facilitates feeding the pump inlet, allowing it to move high viscosity materials.

To create your own pump that will meet your application specifications, you will have to select:

  • The correct air motor according to the maximum pressure,
  • The construction materials according to the nature of the product,
  • The foot and mounting style according to the product packaging, and your installation
  • The Seal pack (see the Documents tab to get all necessary information on our website).

Our air motors are designed for maximum airflow with a pilot distributor to allow fast inversion . They are equipped with a large silencer to avoid water freezing at the motor outlet and can be controlled (start / stop) from a remote air control.

These pumps are used as feeding equipment directly from open drums installed on a elevator using a follower plate. Specific pumps can be used on manifold applications.

Maximum fluid pressure : 180 bar / 2600 psi Maximum air pressure : 6 bar / 87 psi Pressure ratio (depending on air motor size) : 18:1 / 30:1 Viscosity : > 50000 cps Maximum temperature : 80 °C / 176 °F Fluid volume per cycle : 910 cc Motor type : 7200, 9200 Weight (fluid section only) : 44 kg / 97 lbs Fluid inlet (follower plate) : 105 mm Stroke : 200 mm / 7.87 inch
Download the complete technical features
