Presentation

With currently four machine versions, the NUCLEUS Rotosonic DX1 presents itself as an individual all-rounder. Simple retooling and unique free-range diversity ensure maximum flexibility in all areas of application. Flat-layed goods, three-dimensional structures, hard-to-reach small parts, closing or closed mouldings – an optimal free arm is available for every application.

Tube 80+ For the production of tubes or sleeves from diameter of more than 80 mm with engine driven anvil-wheel.
Optional accessories:
– Various material guides
– Automatic material-stopper

Tube 50+ Complex, round-milled Free arm for the production of tubes or sleeves from a diameter of more than 50 mm with engine driven anvil-wheel
Optional accessories:
– Motorized material removal (puller)
– Material spreader

Mini Tube

Special arm for tubes with a diameter of more than 8 mm. An automatic cutting device is also available.

Technical features

Ultrasonic frequency : 35kHz Ultrasonic generator : NUCLEUS Digital Generator DG1 1000W Sonotrade TC12 : 12mm wide cutting sonotrode Contact pressure : Digital NUCLEUS press unit with 600 N contact force (without air pressure) Speed : max. 24,3 m/min Number of drives : 2 Welding width : max. 12 mm Handling of the machine : 11 “multi-touch display Power supply : 230 V, 50 Hz reversible to 110 V, 60 Hz
