Fully and semi-automated machine solutions for tube and bag production | NUCLEUS

Ultrasound welding machine

Vote

Ask for a quote

Presentation

NUCLEUS offers through an in-house development and design team, the possibility fully and semi-automated machine solutions, according to your requirement. Among our standard product range we are also specialized in hose and bag machines, entire splicing units and special systems for transverse welding. Our in-house development and engineering can realize every special customer request.

Tube production with camera guided edge tracking

NUCLEUS developed an elaborate solution for production of conical tubes. The welding unit is moved by linear engine as it is controlled via camera systems which guide it along the materials edge. The result is a precise welding seam parallel to the edge of the material and applicable to any contour.

Technical features

Ultrasonic frequency : 35kHz Ultrasonic generator : NUCLEUS digital generator DG1 400W Sonotrade TC12: 12mm wide cutting sonotrode Contact pressure : Digital NUCLEUS press unit with 600 N contact force (without air pressure) Speed max. : 24,3 m/min Number of drives : 2 Welding width : max. 12 mm Handling of the machine : 11“ Multi-Touch-Display Power supply : 230 V, 50 Hz reversible to 110 V, 60 Hz
