3 axis CNC machine | MECAPLUS

Precision milling machine of simple use for machining rigid plate materials in strong thickness in the sectors of plastic, modeling, aeronautics, aluminium transformation advertising and POS or for machining 3D molds and models.

STRENGTHS

• Designed and realized for an intensive use.
• Particularly adapted for the machining of aluminium, plastic materials of strong thickness and composite materials with high mechanical properties.
• Precision milling machine, easy to operate, for the machining of rigid sheet materials of strong thickness, in the fields of plastic processing, modelling, aeronautics, aluminium processing, advertising and POP… or for the machining of moulds and 3D models.
• Equipment with fixed table – working travels 1500x3100 mm till 2500x6000 mm as standard.
• Many customization possibilities.
• Innovative and efficient vacuum tables with turbine technology or vacuum pumps.
• MECANUMERIC numerical controls as standard or SIEMENS or HEIDENHAIN type.
• Quality kinematics integrating industrial components supplied by the world leaders

Materials to be used (according to the selected spindle and tool):

• Plastic in rigid plates (PMMA-PC-PS-PVC-ABS..)
• Expanded plastic and alveolar plates
• Rigid foams (PU- PS-…)
• Semi rigid foams (KAPA line®,…)
• Composite materials for building : Alucobond®, Dibond®, Reynobond®,..
• Composite materials for industry (polyester resin loaded with glass fiber, carbone fiber...)
• Wood and by-products
• Polyester resins
• Light alloys with Aluminium or copper basis
• Steel and stainless steel
• Soft stones, marbles, granite

OPTIONS :

• Suction of milling chips by professional suction devices
• Various vacuum tables
• Rotative tool shop
• Tool coolant by oil spraying / Toool-material cooling system
• SIEMENS Numerical Control and SIEMENS servomotors
• FANUC Numerical Control and FANUC servomotors
• Automatic debatcher for holding material VILMILL®
• Multi-heads system (2, 3 or 4 heads) for simultaneous machining of several parts
• Overall protection enclosure
• System of automatic loading unloading by cross bar or interchangeable tables.
