Methylene blue leak tester CTE-Bi ACRN

Methylene blue leak tester CTE-Bi

Leak testing

Vote

“ Pneumatic For blisters, bottles, containers Compact ”
Ask for a quote Receive Documentation Contact the supplier


The CTE-Bi is an entirely pneumatic leak detector that allows you to test the tightness of blister packs or pouches, typical of the pharmaceutical industry, by means of vacuum and the migration of a tracer product called methylene blue.

It is composed of an entirely pneumatic and enclosed system which, fed by compressed air, creates a pressure difference between the inside and the outside of your sample. ACRN has standard cover boxes (see prices and options) but also makes custom-made boxes according to the customer's needs.

Your product is immersed during this test in a methylene blue type dye thanks to a perforated grid attached to the lid. A leak is detected if the methylene blue has infiltrated inside the sample during the return to atmospheric pressure.

Compact With methylene blue Type: vacuum, pneumatic Connection to compressed air with a pressure relief of 6 bars by means of an 8 mm diameter rilsan connection. Adjustable time up to 999 seconds with an optional 99,999 seconds digit. Vacuum adjustment knob Perforated grid or watertight tray + removable presser + drip tray Maximum pressure of - 850 mbar readable on a manovacuometer with needle STANDARDS: ASTM D3078, ISO 8871-1
Download the complete technical features

Agri-food Pharmaceutical

Drop your rating on Methylene blue leak tester CTE-Bi

Your answer to the rating from -

Do you provide methylene blue test on microfilm rolls? Can provide a quote?
